STRF016 Seires High current power common mode inductor,Surface Mounted Common Mode Choke Inductor with case,Horizontal

FEATURES:

· Designed for DC/DC converters
· Wide variety of inductor sizes and current ratings are available
· Carrier tape packing used for SMT
· Magnetically shielded construction
· Suitable for reflow SMT Craft soldering.
· Lead free products, RoHS compliant.

· Common mode chokes for AC Power lines
· High impedance to minimize common mode noise
· Excellent EMI performance
· Operate temperature range :-40 ℃to + 125℃(Including self temperature rise)
· Storage temperature range: -40℃to +125℃

COMMON APPLICATIONS:

· DC/DC, AC/DC converter
·Filter and Noise suppression
· Communication System
· Automotive Systems
· Liquid Crystal Televisions

TECHNICAL INFORMATION:

·IDC: Temp. rise 40℃ Max
·lnductance test: HP4284A 100KHz 0.1V
·RDC:QuadTech 1880 Milliohmmeter
·Solder methods: Vapor Phase, Infrared Reflow
·Resistance to soldering heat:260℃ for 10 seconds
·Solvent resistance: Conforms to MIL-STD-202E
·Weight------------------1.5grams TYP
·Tape & Reel--------------700/reel

More sizes to choose from
